Aerospace technology
Extreme wideangle for airstream tests
IB/E optics was tasked by the German Aerospace Center (DLR) to further develop the pressure measuring system for wind tunnel models.
With UV-lighting and IB/E optics’ special varnish (Pressure Sensitive Paint PSP) evinces different intensities according to the pressure ratio applied. With a specifically designed ultra-wide angle lens IB/E optics is not only able to detect but also to record varying intensities.
Client: German Aerospace Center (DLR)
High‒speed setup including four channel UV to NIR lens setup
High‒ speed camera system with four channels each transmitting 200 to far NIR region, used for example for NASA.
Only fused silica and CaF2 glasses used – no coating.
Optical system layout and assembly.
Using common UV Nikkor front lens with a customized field system.
Client: PCO
Cassegrain Mirrorlens System
Customized mechanical design on a Cassegrain telescope 4000 mm.
